INLINE TUBE FAN RUCK EM 150 E2 02
GUARANTEED SAFE CHECKOUT 💳
INLINE TUBE FAN RUCK Etamaster EM 150 E2 02
Ruck ventilators GmbH is a best-known brand in the ventilation industry, known for producing top-quality products that regulate climate and ventilation. Made in Germany.
RUCK EM 150 E2 02 - Up to 270 m³/h
- Innovative, high-efficiency diagonal fan
- Optimally tuned, CFD-optimized aerodynamics
- Housing made of impact-resistant, reinforced polypropylene
- Robust single phase AC motor
- Conveyed medium temperature up to 40 °C in continuous operation
- Integrated thermal switch
- The benchmark for efficiency since 2012
- Made in Germany
RUCK EM 150 E2 02 – 150 mm Inline Tube Fan
The Ruck ETAMASTER inline tube fan (EM series) can be operated with an on/off switch.
The Etamaster has a built-in thermal switch to prevent burn out. In addition, the inline tube fan is equipped with a Mixed-Flow impeller with stator, as a result of which the fan will still produce a low sound level at a high flow rate.
The EM series is available with capacities ranging from 124 m³/h to a maximum of 315 m³/h and with diameters ranging from 100 mm to a maximum of 160 mm respectively.
TECHNICAL DATA
|
Connection diameter |
150 mm |
|
Number of phases |
1~ |
|
Number of poles |
2 |
|
Control |
On/Off |
|
Category code |
35 |
|
Weight |
0.98 kg |
|
IP Motor |
IP00 |
|
Insulation Class Motor |
F |
|
Max. Operating Current |
0.29 A |
|
Max. pressure |
125 Pa |
|
Max. Air Volume |
270 m³/h |
|
Max. Current Consumption |
0.29 A |
|
Max. power consumption |
29 W |
|
Max. Static Efficiency |
10 % |
|
Max. allowed Medium Temperature |
40 °C |
|
Max. allowed Medium Temperature at Rated Current |
50 °C |
|
Max. allowed Ambient Temperature |
40 °C |
|
Max. allowed Ambient Temperature at Rated Current |
50 °C |
|
Max. number of revolutions |
2600 1/min |
|
Max. Total Efficiency |
10.6 % |
|
With timer |
No |
|
Min. Operating Temperature |
-25 °C |
|
Motor Protection |
TAI |
|
Motor type |
Gap pole |
|
Nominal frequency |
50 Hz |
|
Rated Speed |
2520 1/min |
|
Nominal power consumption |
29 W |
|
Nominal voltage |
230 V |
|
Nominal current |
0.28 A |
Click for more detail
PRODUCT DATA.PDF
