The Ruck MPS EC T series box fan features an energy-efficient EC motor positioned outside the air stream. This design ensures that contaminated or greasy air of up to 120°C does not pass through the motor, making the fan ideal for use in catering and kitchen environments. The motor supports variable speed control via MTP 20, constant pressure regulation, or 0-10V control. For duct connections, the Ruck fast clamp is recommended to minimize vibration and noise.

MPS 355 EC 30

• Backward curved centrifugal impeller
• Swing out fan unit
• Sheet steel housing double-walled, 40 mm mineral wool
• High efficiency EC motor outside the air flow
• Conveyed medium temperature up to 120 °C in continuous operation
• With condensate and grease drain


The fan is designed for easy maintenance and allows for condensation and grease extraction. The MPS EC series offers airflow capacities from 2220 m³/h up to 6975 m³/h, with diameters ranging from 200 mm to 355 mm.

Specifications

• Number of phases: 1~
• Type of motor control: 0-10V
• Category code: 35
• Weight: 54.7 kg
• IP Motor: IP54
• Insulation Class Motor: F
• Max. Operating Current: 10.7 A
• Max. pressure: 1240 Pa
• Max. Air Volume: 5400 m³/h
• Max. Current Consumption: 10.7 A
• Max. power consumption: 1511 W
• Max. Static Efficiency: 57.8 %
• Max. allowed Medium Temperature: 120 °C
• Max. allowed Medium Temperature at Rated Current: 120 °C
• Max. allowed Ambient Temperature: 50 °C
• Max. allowed Ambient Temperature at Rated Current: 50 °C
• Max. number of revolutions: 2550 1/min
• Max. Total Efficiency: 60.8 %
• Min. Operating Temperature: -20 °C
• Motor Protection: TEC
• Motor type: EC
• Nominal frequency: 50 Hz
• Rated Speed: 2550 1/min
• Nominal power consumption: 1511 W
• Nominal voltage: 230 V
• Nominal current: 10.2 A
