Helty Flow 800 (Version Pure) Decentralised Commercial MVHR System for Schools & Offices
Helty Flow800 Decentralised MVHR Ventilation Unit (Version Pure)
Core Advantage: Simplified, Clean Installation and Quick Retrofitting
-
Minimal Structural Impact: This decentralised ventilation system does not require long, bulky ductwork throughout the space. Installation requires drilling just two 250 mm diameter holes through the exterior wall (2x Ø250 mm).
-
Significant Cost Savings: Eliminates the budget needed for ductwork design, materials, and installation, as well as the need to hide ducting behind drywall or suspended ceilings.
-
Fast Commissioning: Installation takes minimal time and avoids long operational downtime, making it ideal for active commercial or residential spaces.
-
Ideal for False Ceilings or Exposed Mounting: Compact design (1320 x 392 x 1020 mm) allows seamless integration into false ceiling spaces or direct exposed mounting with optional steel covers.
CLICK FOR MORE DETAILS – CATALOGUE
CLICK FOR MORE DETAILS – TECHNICAL DATA SHEET
Detailed Overview of Capabilities and Technological Features
-
High Performance and Flexible Airflow Control:
-
Wide airflow adjustment range: 300 / 350 / 500 / 600 / 700 / 800 m³/h.
-
Multiple operating modes: ultra-quiet Night Mode, 4 standard speeds for everyday comfort, and a Hyperventilation (Boost) mode for rapid airing out.
-
-
Advanced Energy Efficiency and Recovery:
-
Enthalpic Cross-Flow Heat Exchanger: Recovers sensible heat (80% thermal efficiency) and moisture, preventing indoor air from drying out in winter.
-
Energy Efficiency Class: A+ (Cold climate) / A (Temperate climate) / E (Warm climate).
-
Specific Energy Consumption (SEC): -77 kWh/(m²·year) for cold / -41.3 kWh/(m²·year) for temperate / -18.1 kWh/(m²·year) for warm climates.
-
-
Quiet Operation and Acoustic Comfort:
-
Sound Pressure Level: 28.6 / 31.3 / 40 / 42 / 44.5 / 49.5 dB(A).
-
Sound Power Level: 43.5 / 46.2 / 54.9 / 56.9 / 59.4 / 64.4 dB(A).
-
-
Multi-Stage Air Filtration and Monitoring:
-
Supply Air (Intake Filter): Dual-stage filtration via Coarse 80% (G3) + high-efficiency ePM1 80% (F9) filter, stopping up to 90% of PM10 and 80% of PM2.5.
-
Extract Air (Extraction Filter): Coarse 80% (G3) filter protecting internal components.
-
Smart Monitoring: Automatic filter check with a pressure sensor that continuously monitors clogging and triggers filter replacement alerts.
-
-
Smart Control & Functions:
-
Comfort function included.
-
Compatible with remote control, removable STD / Cloud control panels, and Helty Home app.
-
Full Technical Specifications and Features (Version STD)
| Parameter / Feature | Value / Details |
| Dimensions (W x H x D) |
1320 x 392 x 1020 mm |
| Net Weight |
75 kg |
| Wall Penetrations |
2x Ø250 mm holes |
| Airflow Rate |
300 / 350 / 500 / 600 / 700 / 800 m³/h |
| Flow Adjustment |
Night + 4 stages + Hyperventilation |
| Power Consumption per Speed |
22 / 26 / 46 / 61 / 90 / 138 W |
| Specific Fan Power (SPI) |
0.07 / 0.07 / 0.09 / 0.1 / 0.13 / 0.17 W/(m³/h) |
| Power Supply Parameters |
Mains: 230 V AC / Internal operating voltage: 24 V DC (Max 0.7 A) |
| Heat Exchanger |
Enthalpy cross-flow |
| Heat Recovery Efficiency |
80% / 76% / 74% / 70% / 69% / 64% |
| Free-Cooling / Free-Heating |
Electronic automatic bypass included |
| Special Modes |
Night Mode, Hyperventilation, Comfort Function |
| Sensors & Alerts |
Humidity sensor, Filter replacement alert (pressure sensor), CO2 sensor and VOC index
|
| Control & Interface Options |
Removable STD / Cloud panel, Remote control & Helty Home app compatible (Option) |
| BMS / Smart Home Integration |
Integrated RS485 serial port (Modbus RTU protocol) included |
| Supply Air Filter |
Coarse 80% (G3) + ePM1 80% (F9) |
| Extract Air Filter |
Coarse 80% (G3) |
| Energy Efficiency Class |
A+ (Cold) / A (Temperate) / E (Warm) |
| Specific Energy Consumption (SEC) |
-77 (Cold) / -41.3 (Temperate) / -18.1 (Warm) kWh/m²a |
| Included Accessories |
Card with QR-code digital manuals, MVHR filters |
| Product Code |
1VMC04022 |
CLICK FOR MORE DETAILS – CATALOGUE
CLICK FOR MORE DETAILS – TECHNICAL DATA SHEET
