DUCT ACOUSTIC FAN VORTICE LINEO 150 QUIET ES
DUCT ACOUSTIC FAN VORTICE LINEO 150 QUIET ES
Mixed flow in-line fan with EC motors and low noise levels
- Spigot size: 150 mm.
- Max Airflow: 515 m3/hr.
- Power Absorbed: 7.7-31 W.
- Sound level: 20.2-30.2 dB(A) radiated 3m.
Description
-
Enclosures made of fire resistant plastic resin, E2 class, according with ISO EN 11925-2: 2010, in areas close to motor and electrical components.
-
Casing integrating a sound-absorbing coating, optimized to minimize sound emissions radiated into the environment and transmitted through exhaust and supply ducts.
-
Nominal diameter 150 mm.
-
EC (brushless) motor, thermally protected, with shaft mounted on ball bearing supports, coupled with a centrifugal impeller.
-
High water resistance: IPX5 (if installed in a duct).
-
Equipped with a thermal fuse overheating safety device.
- Speed adjustable through potentiometer (0-10V signal) or two-speed switch (to be set at the installation in a preset range).
